Product Description
Sumitomo Thermal Jacket Remover - JR-7
The JR-7 includes a new ergonomic design with a tough metal lid for durability, vibration-ready notification, LED light for dark environments, a wide and flat stage for easy setting and cleaning, power save and auto power off functions, and improved blade design to reduce operation force.
Features
- Compatible with 200 & 250um fiber ribbons
- Ready notification by Vibration
- LED lighting illuminates the heater area
- IPx2 Water protection and shock-resistant
- Field replaceable blade and battery for Easy maintenance
Specifications
| PROPERTY | SPECIFICATION |
|---|---|
| Applicable Fiber | Coating material: UV Cured Resin Coating Thickness Single Fiber: 200 to 400um Coating Thickness Ribbon Fiber (2 to 12f): 200 to 400um Cladding Diameter: 125um |
| Coating Removal Length | 35 mm |
| Power Source | 1) AC Input Voltage AC 64 – 90V, 50/60Hz Adapter Output Voltage DC 12V 2) DC Input (Power Supplied from Fusion Splicer) Output Voltage DC 9 -15V 3) Battery Operation (with BU-JR6B) Battery Voltage: 7.4V Battery Capacity: 1620mAh |
| Number of Removal Cycles | Approx. 600 (Power Save Mode) |
| Features | 1) Temperature Settings: 4 levels (Min. 80 to Max. 140 ℃) 2) Normal Mode / Power Save Mode 3) Battery Remaining Capacity Indicator 4) Vibration notification 5) LED lighting on the heater |
| Environmental Conditions | Operating Condition: Temperature: 0° ~ +40° C, Humidity: 0% to 95% (Non-Condensing) Storage Condition: Temperature: -40° to +60 °C, Humidity: 0% ~ 95% (Non-Condensing) |
Physical Characteristics
| Property | Specification |
|---|---|
| Height | 1.5 in (38 mm) |
| Width | 1.8 in (45 mm) |
| Depth | 5.7 in (138 mm) |
| Weight (Including Battery) | 0.56 lb (235 g) |
